MODEL GE - 420
MODEL GE - 420
MACHINE SPECIFICATION
MACHINE SPECIFICATION
| Machine model | GE-420T |
| Packing speed | 5-60 bags/min (Subjected to the filling weight) |
| Bag width range | 60-200mm |
| Bag length range | 80-300mm |
| Machine power | 220V, 50/60Hz, 3Kw |
| Weighing system | 10-head with 1.6L weighing scale |
| Air pressure | 0.65Mpa, 3m³/min, 6kg/cm² |
| Filling range, Accuracy | 150-1500ml, ±0.3% |
| Machine material | SUS 304 Stainless Steel |
| Package material Thickness | 40-120 microns |
| Packaging material | Composite film, aluminum film, etc. |
| Film Roll diameter | Max. 360mm |
| Bag cutting shape | Serrated edge (for easy-to-tear-open bags) |
| Bag type | Back sealing pillow bag |
